Fox ESS CT Clamp - compatible with AC, HY & AIO ranges

FE-AIO-C | Split-core current transformer for export limitation and consumption monitoring on Fox ESS AC, Hybrid and AIO inverters.

Key Features

• 100A / 33.33mA split-core CT clamp (CTA016 specification).
• Compatible with Fox ESS AC chargers, hybrid inverters and AIO storage systems.
• Activates export limitation functionality to prevent grid export.
• Secondary CT option for tracking additional generation sources (wind, hydro, extra PV arrays).
• Simple clip-on installation - no need to disconnect live conductors.
• Non-invasive monitoring of single-phase AC current at consumer unit or supply position.

Function & Application

This CT clamp installs around the main live conductor to measure real-time import/export current, feeding data to the Fox ESS inverter for precise export control and energy monitoring. Essential accessory for zero-export installations and systems requiring accurate consumption tracking.

Technical Specifications

Primary Current	100 A
Secondary Output	33.33 mA
Core Type	Split-core (clip-on)
Accuracy Class	Class 1.0
Compatible Series	AC, Hybrid, AIO inverters
Cable Diameter	Up to 20 mm

Installation Notes

• Installs on L1 live conductor at consumer unit or main supply for single-phase systems.
• Connects directly to inverter's CT input port via supplied cable.
• Orient correctly (K1 → L direction) for accurate current direction sensing.
• Secondary CT use requires inverter configuration for multi-source monitoring.

MPN: FE-AIO-C
Model: Fox ESS CT Clamp (100A/33.33mA)

Essential accessory for compliant zero-export Fox ESS installations and accurate energy monitoring across AC-coupled, hybrid and all-in-one storage systems.
